Slim Turnstile RS 916-2

Slim Turnstile RS 916-1 Also Called(Speed Gate,Speedlanes,Swing Turnstiles,Wing Turnstile) Chassis is made of 304 SUS Stainless Steel;Speedgates Turnstiles RS 916-1 consist of (motor,mechanism,swing barriers,led lamp,buzzer,battery,sensors,electric circuit),and so on;Speedlanes Turnstiles RS 916-1 has different program for pedestrian or bicycle,word with high sensitivity sensors to en sure safety of people.Swing Barrier RS 916-1 swing door provides flexible passageway access control,the control with from 300-1600mm.Slim Gate RS 916-1 with standard fire interface,arm can drop down for evacuation even power is not cut off when fire alarm triggered.Slim Turnstiles RS 916-1 Compatible with various access controllers (such as Coin Insert,Fingerprint,Facial Recognition,RFID etc.);Swing Turnstiles RS 916-1 is widely used in Factory,Subway,Gym,Cinema,Stadium,Ferry,Hospital,School and other Public places;Wing Turnstiles RS 916-1 can external third-party devices such as: qr code,barcode,coin insert,push button,reader,wheel and so on;

Product Name

Slim Turnstile

Model

RS 916-2

Drive Motor

DC Brushless,Servo Motor(Optical)

Material

304 Stainless Steel;2.0mm thickness;

Dimension

1600*130*1000mm（stadrad);168*980mm(cylinder)

Net Weight

   60kg/pcs,70kg/pcs

Passing Direction

Single directional / Bi-directional

MCBF

5 million

Working Environment

Indoors or outdoors with shed

HS Code

8608009000

Power Supply

AC220V/110V, 50/60Hz

Operation Voltage

24V DC

Power Consumption

20W

Operation Temperature

-15 ° C – 60 ° C

Flow Rate

40-45 people per minute

LED Indicator

Yes

Emergency

Automatic arm drop when power off

Communication Interface

RS485 (Distance: <=1200m), TTL232

Access Control

barcode,ic/id card,face recognition,fingerprint etc;

*Slim Turnstile is designed to control pedestrians entering or exiting restricted areas, usually used of high pedestrian traffic flow in both directions.

*The body is made of brushed stainless steel and black rubber.

*Speed Gate is ideal for both indoor and outdoor settings.

*Swing Turnstile has standard relay signal, which can be integrated with any kind of third-party access control system (e.g.: RFID, Fingerprint and Biometric reader device).

*Slim Barrier has sufficient space, which can mount with any type of external device.( e.g.: Display, Counter, Reader, Push button, Card collector, Coin insert, Barcode/QR reader).

*In case of emergency, the optical turnstile arms will open automatically to allow free passage.

*Slim Gate support standard and handicapped type with wide passageway, wheelchair, pedestrian with large luggage can pass.

*Slim Turnstiles is suitable for areas with general pedestrian traffic.(e.g.: Hotel, Building, Dormitory, Station, Supermarket)

^Long-life performance, high operation dependability and fast response.

^The whole system runs smoothly, low noise, no mechanical impact.

^Single directional or Bi-directional is selectable.

^Automatic reset function: swing arms will lock automatically within 5s (can be setting) if passenger delay to entry.

^When power is off, swing arms will open automatically, which is complying with fire safety requirements.

^LED indicator (red × means no entry; green →means entry). Easy to install and maintain.

^3-year warranty support.

^Infrared sensor alarm function, in case of illegal intrusion and reverse intrusion.

^Anti-intrusion function, the turnstile is locked automatically until valid opening signal input.

^Anti-reverse function, the turnstile alarms if someone wants to entry in the reverse direction.

^Anti-trailing function, the turnstile alarm if someone wants to burst in without permission.
