Half Height Turnstile RS 995-M

Model RS 995-M
Size RS 995-M
Material 304 Stainless Steel
Brand RS Security
Origin Guangdong China
Certificate ISO,CE,SGS
Chat Now
Contact Us

Half Height Barrier RS 995-M Also Called(Waist Height Turnstile,Half High Turnstile,Half High Barrier,Half Height Turnstile) is an upgraded product of Tripod Turnstile.Half Height Door RS 995-M full body made of 304$ stainless steel;case thinckness is 2.0mm.Half Height Gate RS 995-M is divided into 120 degrees and 90 degrees, mainly used for the management of the channel entrance and exit, with eliminate illegal access, safety,convenience and in the case of emergency quick control of free access and other characteristics.Half Height Turnstile RS 995-M consist of electromagnetic, electric circuit,mechanism,bars,hydrulic damper,led lamp and so on.Half Height Barrier RS 995-M with standard fire interface,arm can be free rotation by force for evacuation even power is not cut off when fire alarm triggered.Half High Barrier RS 995-M anti-passback,with ydraulic damper,low impact sound and high durability.Half High Turnstile RS 995-M is widely used in stations, docks,factory,airports,scenic spots, parks, smart communities, prisons and other occasions.Waist Height Turnstile RS 995-M strong pit rust ,durable,waterproof and light proof,corrosion resistance,high temperature resistance,and still as new after many years of use.


Product Name

Half Height Turnstile


RS 995-M



Framework Material

304 Stainless Steel;2.0mm thickness;







Angle Degree

≤90/120 degree

Arm Length


HS Code


Power Supply

AC220V/110V, 50/60Hz

Operation Voltage

24V DC

Power Consumption


Operation Temperature

-15 ° C – 60 ° C

Flow Rate

20-25 people per minute




Automatic arm drop when power off

Communication Interface

RS485 (Distance: <=1200m), TTL232

Access Control

barcode,ic/id card,face recognition,fingerprint etc;



* Electric control adopts electromagnet to drive safe and reliable;

Power-off and gate-opening functionAfter power off, the gate lever is automatically unlocked and becomes a free passage mode, which is convenient for evacuation of people;

*Anti-rotation functionAfter the brake lever is rotated to a certain angle, the strong reverse rotation of the brake lever will be regarded as retrograde, and the system will automatically lock to prevent pedestrians from moving backward;

*The shape can be brushed stainless steel or sprayed, and the color is optional.

*Brushed stainless steel, rust-proof, strong and durable


Customized extension functions:

1. The all-stainless steel rainproof box is novel and beautiful.

2. It has a personalized installation interface (such as card reader, indicator light installation, etc.) to ensure that the control gate equipment of the system integrator is simple and convenient during installation.

3. The movement of the turnstile has an automatically adjustable hydraulic shock absorber. When the turnstile is used for movement, the sound is very small, no impact, and the brake lever automatically decelerates back to the center. The surface of the movement is electroplated with yellow dichromate.

4. It can be programmed with gate control, one or two direction control (set by the user).
