Half Height Turnstile RS 995-1

Half High Turnstile RS 995-1 Also Called(Half Height Turnstile,Half Height Barrier,Half High Barrier,Waist Height Turnstile) is an upgraded product of Tripod Turnstile.Half Height Barrier RS 995-1 full body made of 304 or 316 stainless steel;case thinckness is 2.0mm.Half Height Turnstile RS 995-1 is divided into 120 degrees and 90 degrees, mainly used for the management of the channel entrance and exit, with convenience,safety, eliminate illegal access, and in the case of emergency quick control of free access and other characteristics.Half Height Door RS 995-1 consist of mechanism,bars,electric circuit,electromagnetic,hydrulic damper,led lamp and so on.Half Height Gate RS 995-1 with standard fire interface,arm can be free rotation by force for evacuation even power is not cut off when fire alarm triggered.Waist High Turnstile RS 995-1 anti-passback,with ydraulic damper,low impact sound and high durability.Waist Height Turnstile RS 995-1 is widely used in factory,airports, stations, docks, scenic spots, parks, smart communities, prisons and other occasions.Half High Barrier RS 995-1 corrosion resistance,high temperature resistance,strong pit rust ,waterproof and light proof,durable,and still as new after many years of use.

Product Name

Half Height Turnstile

Model

RS 995-1

Brand

Bloccate

Framework Material

304 Stainless Steel;2.0mm thickness;

Size

1400*280*980mm

Weight

   120KG

Blades

3PCS

Angle Degree

≤90/120 degree

Arm Length

≤510mm

HS Code

8608009000

Power Supply

AC220V/110V, 50/60Hz

Operation Voltage

24V DC

Power Consumption

20W

Operation Temperature

-15 ° C – 60 ° C

Flow Rate

20-25 people per minute

barrel

connecting

Emergency

Automatic arm drop when power off

Communication Interface

RS485 (Distance: <=1200m), TTL232

Access Control

barcode,ic/id card,face recognition,fingerprint etc;

* Electric control adopts electromagnet to drive safe and reliable;

Power-off and gate-opening functionAfter power off, the gate lever is automatically unlocked and becomes a free passage mode, which is convenient for evacuation of people;

*Anti-rotation functionAfter the brake lever is rotated to a certain angle, the strong reverse rotation of the brake lever will be regarded as retrograde, and the system will automatically lock to prevent pedestrians from moving backward;

*The shape can be brushed stainless steel or sprayed, and the color is optional.

*Brushed stainless steel, rust-proof, strong and durable

Customized extension functions:

1. The all-stainless steel rainproof box is novel and beautiful.

2. It has a personalized installation interface (such as card reader, indicator light installation, etc.) to ensure that the control gate equipment of the system integrator is simple and convenient during installation.

3. The movement of the turnstile has an automatically adjustable hydraulic shock absorber. When the turnstile is used for movement, the sound is very small, no impact, and the brake lever automatically decelerates back to the center. The surface of the movement is electroplated with yellow dichromate.

4. It can be programmed with gate control, one or two direction control (set by the user).
